KT011-Key Inspector
Requirements: AMS
KT011 - Key Inspector is an additional software function which allows you to read all the data from a key. It works together with the Abrites PROTAG Programmer.
Once you place the key in the PROTAG programmer and read it using Key Inspector, you will see all the information contained inside the key. This depends strongly on the type of key but you can typically expect to see details ranging from the type of transponder for older key types, to full, detailed information such as:
- Key type
- Vehicle Identification Number (VIN)
- Vehicle colour code
- Vehicle Type
- Time and date of last drive
- Battery voltage
- Quantity of fuel in the tank
- Mileage stored in the key
- ALL POSSIBLE INFORMATION CONTAINED IN THE KEY
• BMW keys:
- Key make - BMW
- Remore control functionality available – YES or NO
- Type of transponder / processor (7935 or 7931) / (ELMOS)
- Position of the key in the immobilizer - "from 0 to 9"
- Fixed code of the key: "16 characters"
- Vehicle equipment data
- VIN number
- Mileage values stored in the key upon last start
• All vehicles
- Transponder ID: xx xx xx xx
- Transponder type – PCF 7936, 7945, 7941, 7961, etc.
- Transponder status – Locked (already programmed) or Blank (not programmed)
• OPEL/VAUXHALL :
- Key make: OPEL/VAUXHALL
- VIN number
- Mileage values stored in the key upon last start
• RENAULT :
- VIN number
- Registration plate (if provided)
- Mileage values stored in the key upon last start
- Fuel level (litres)
- Oil level (proportion)
- Date of return
- Date of the technical inspection (if provided)
Owner data:
Company
First name
Name
or Tel. Mobile
or Tel. Fix
City
Address
• BMW:
- Key make – BMW
- Remote control functionality available / Hands-free
- VIN number
- Vehicle colour code
- Interior upholstery (UPH code)
- Key blade cutting code
- Frequency of the remote control
- Position of the key in the immobilizer - "from 0 to 9"
- Date of first registration of the vehicle
- Mileage values stored in the key upon last start
- Date / time of the last use of the key
- Fixed code of the key: "16 characters"
- Fuel level (litres)
- Battery voltage
- Outside temperature
- Coolant temperature
Example:
- Hitag 2 key type
- Key Identifier : B5 B1 7D 97
- Micro controller inside key is PCF 7945.
- The transponder is NOT blank
- This key is from BMW vehicle
- Key is WITH remote control.
- VIN : WMWZC51000WK70320
- Colour code of the vehicle : 0A48
- UPH code of the vehicle : FSGZ
- Key blade cutting code : 4B7490
- Key remote control frequency 868 MHz
- Key is programmed in position : 1
- First registration of the vehicle : 15/12/2010
- Odometer value while last usage of the key : 165247
- Last time when this key is used : 21/02/2019 18:11
- Fuel in the tank (litres) : 0
- Battery voltage : 14.970
- Outside temperature : 17.50
- Coolant temperature : 68
Transponder ID
Transponder ID
Transponder status – Locked (already programmed) or Blank (not programmed)
Transponder ID
Transponder ID
Transponder ID
Transponder ID
Transponder ID
• PORSCHE keys:
- VIN number: xxxxxxxxxxxxxxxx
• BMW keys:
- Date of first registration of the vehicle
- Chassis type
- Current VIN
- Vehicle colour code
- Interior upholstery (UPH code)
- Mileage values stored in the key upon last start
- Date / time of the last use of the key
- Fuel level (litres)
- Battery voltage
- Outside temperature
- Coolant temperature
- Position of the key in the immobilizer - "from 0 to 9"
- Key blade cutting code
- Date of creation of the key
- Initial VIN
- Remote control code
Transponder ID
Transponder type
• RENAULT
- VIN number
- Registration plate (if provided)
- Mileage values stored in the key upon last start
- Fuel level (litres)
- Oil level (proportion)
- Date of the technical inspection (if provided)
Owner data:
Company
First name
Name
or Tel. Mobile
Transponder ID
Transponder ID
Position of the key in the immobilizer
Transponder status – Locked (already programmed) or Blank (not programmed)
Mileage values stored in the key upon last start
The last 8 records of mileage (KM + Date)
Transponder ID
Transponder ID
Transponder status – Locked (already programmed) or Blank (not programmed)
Transponder ID
Transponder ID
Key type (FBS3/FBS4)
SSID – identifier
Position of the key in the immobilizer
Key usage counter
Functional type
Firmware version
Sub-data
Operational status
Hands-free
User data 1
ID card
Type card
Depending on the type of key, the information shown can be full or partial.
KT011 is extremely useful for insurance agencies, law enforcement and independent service shops, but can also be used by locksmiths.
An active AMS and PROTAG are required in order to be able to use KT011 - Key Inspector.
