Name: MN038 - Cluster Calibration IC223 2020+/IC177 2023+ (Visteon R7F701529 BGA)
SKU: MN038
Price: 725.0 USD
Availability: InStock

MN038 - Cluster Calibration IC223 2020+/IC177 2023+ (Visteon R7F701529 BGA)

Store / MERCEDES

Product Details

The MN038 license allows you the exceptional ability to calibrate IC223 (2020+) and IC177 (2023+) clusters in Mercedes-Benz vehicles, equipped with Visteon R7F701529 BGA processors. This software license ensures a safer and simpler process, not requiring any work with the EZS (EIS) module - it is neither needed, nor affected during the procedure. Synchronisation between the EZS (EIS) module and the Instrument cluster is blocked without the need to use a filter! All operations are carried out directly on the IC223/IC177 cluster PCB for maximum efficiency and reliability.

Functionality:

Adjust the mileage value in the IC223 (2020+) / IC177 (2023+) clusters in Mercedes-Benz vehicles, equipped with Visteon R7F701529 BGA processors

Block the synchronization of the mileage with the EZS module (no need to use any type of filter in the vehicle!)

Supported Models:

IC223 (2020+) in Mercedes-Benz vehicles, equipped with Visteon R7F701529 BGA processors:

W223 S-Class 2020+

W206 C-Class Sedan (Saloon) 2021+

S206 C-Class Station Wagon (T-model) 2021+

V206 C-Class Long Wheelbase Sedan 2021+

X206 C-Class All- Terrain 2021+

X254 GLC 2022+

C254 GLC Coupe 2022+

C236 CLE Coupe 2023+

A236 CLE Cabriolet 2023+

Other models with the IC223, equipped with Visteon R7F701529 BGA processor

Including models after 2023 with IC177, equipped with Visteon R7F701529 BGA processor, such as:

W177 A-Class

W243 B-Class

W247 B-Class

H243 EQA- Class

X243 EQB- Class

C118 CLA- Class

H247 GLA- Class

W167 GLE/ GLS- Class

X247 GLB-Class

W257 CLS-Class

X290 AMG GT Four Door Facelift

The procedure requires working with the IC223/IC177 module's PCB on bench, unsoldering a few capacitors and soldering the wires to the CB501 cable onto it. Wiring diagrams are included within the software for guidance. If alternative wiring is required for specific modules, please contact support@abrites.com for additional diagrams and assistance.

In order to connect and work with the IC223/IC177 cluster successfully, you will need the ZN085 RH850/V850Programmer and the ZN092 adapter.

We hope to have the ZN092 in stock soon!

AVDI and Active AMS are required!

ABRITES USA USER MANUALS

ABRITES USA VIDEOS

Please enter AVDI# in the notes section when checking out. This is required to complete the order processing.

The normal turnaround time for software link processing, is 1-2 business days.

ALL SOFTWARE SALES FINAL!

User of these products accepts full legal responsibilities for proper usage. These products are intended for legal use only. ABRITES USA does not condone or accept any responsibility for misuse of it's products.
